2012年12月28日 星期五

T1800 (Super Thin ITX Chassis)

Model No.: T1800 (Super Thin ITX Chassis)

Specification
Dimension (mm): 190 (H) x 36 (D) x 190 (W) = 1.3L, with front Panel
Color: Black
Form Factor: Mini ITX Case
M/B type: Intel DN2800MT
Intel DH61AG (Low Profile CPU Cooler Solution)
Intel DQ77KB (Low Profile CPU Cooler Solution)
* Compatible Processor(s) for Board "DQ77KB"
Other brands Low Profile Motherboards
Front: USB (V2.0) * 1, Power/HDD Led, Antenna hole (Pre-punch)
Power Supply: M/B DC on Board
System Fans: Fan * 2, Heatsink
Options: Ear Brackets, VESA Bracket_TV
Application: Thin Client, Digital Signage








2012年12月16日 星期日

Morex Mini-ITX PC: Model No.: T1700 (Ultra Skinny form factor PC)

Morex Mini-ITX PC: Model No.: T1700 (Ultra Skinny form factor PC): Specification CPU: Intel Atom Cedar Trail   N2600/N2800/D2550   Intel NM10   Intel GM3650   Memory: DDR3 2G (MAX 4G)   HDD: SSD 32G   Res...

Maxwell Ultra PC- T1700 (Ultra Skinny form factor PC)



Specification
CPU: Intel Atom Cedar Trail
N2600/N2800/D2550
Intel NM10
Intel GM3650
Memory: DDR3 2G (MAX 4G)
HDD: SSD 32G
Resolution: LCD 1024 * 768
VGA: Gen3.5 GFX Core
GFX Render Core Frequency @ 133 MHz
CRT: QxGA 2048 x 1536
WiFi: 802.11 b/g/n
Audio: HD Audio
Mini PCIE: 2 * Mini PCIE

I/O Port
*LAN Port (RJ45)
*VGA Port
*DVI Port
*HDMI Port
*SPDIF
*Audio Port - Headphone, MIC
*Power Port
*USB Port: 4 * USB 2.0

Sys. S/W
BIOS: AMI BIOS

OS support (Optional)
Win XP, Win 7, Linux

Power Supply
60W (19V/3.15A max & 60W max DC output ) A/C
100-240V AC 50/60HZ 1.0A Max

Power Managment
ACPI V2.0
*Power button




2012年11月2日 星期五

MPC-2000 (IPC) -- Fanless


Based on Intel Atom N2600 processor. compared with last generation, with power saving and performance upgraded. support full HD decoder. idea for embedded system. Intel Atom N2600 with low TDP design(3.5W), support Passive solution. Support I/O: D-SU
Model No.: MPC-2000 (IPC)

Specification:
Processor: Intel Atom N2600 1.6GMz Dual Core
System Chipset: Intel NM10
Memory: Support 1 x 204-pin DDR3 SO-DIMM-800MHz (Max up to 4GB)
Graphic Chipset: Intel intergrated graphics GMA3600, support 3D, 2D and Video Capabilities, DX10.
Display: - HDMI: up to 1920 x 1200 resolution
- VGA: 1920 x 1200
Storage: Support 2.5" SATA HDD/SSD
Ethernet: 2 x Realtek 8111E (10/100/1000 Mbps)
Audio: Realtek ALC662-channel HD audio CODEC
Power: Input Voltage: 12V (DC in)
OS Support: Windows 7, Windows XP, Linux
Dimension: 210 x 139 x 41mm

I/O Interface
-Front
2 x com port
2x USB 2.0/1.1 port
Power Button
-Back
1x DJ Jack
1x HDMI
1 x D-SUB
2 x GigaLan (RJ-45)
4x USB2.0/1.0 port
1x audio-out
-Internal
1 x Mini PCI-E x1

Application:
Digital Signage
Automation






2733-H61 i3 Barebone PC (WiFi)

2733-H61 Barebone PC (WiFi)
Model No.: 2733-H61 Barebone PC (WiFi)

Specification:
Dimension: 63.5 (H) x 295 (W) x 300 (D)
Volume: 5.6L (Mini ITX Chassis 2733 - Metal (Front Bezel is Plastic)
Single Pack Weight: N.W. 4.0 KGs, G.W. 4.5 KGS
CPU: Intel i3-2120 processors, 3.3GHz/3MB Cache
Chipset: IntelR H61 Express Chipset
Memory: Single-Channel DDR3 with two connectors for 1066/1333 Mhz Channel SO-DIMM Memory Support, 4GB x 1
Graphic: Requires Intel Core Processor with Intel HD Graphics
Expansion Slot: 1 x PCI, 2 PCI-Express*Mini Card (1-full size, 1-half size)
Audio: Realtek ALC892 7.1 Channel HD Audio
LAN: Realtek RTL8111EVL PCI-E Gigabit LAN with Enhanced Surge Protection
Storage Bay: 3.5" STATA II HDD, 500GB HDD
Power Button Power Buttom: x 1 @ Rear Panel
Front Panel I/O: USB 2.0 Port: x 2
M/B Bank Panel Connectors :
1 * 19V DC-in Jack
2 * USB 3.0
1 * DVI-I
1 * HDMI
1 * eSATA
2 * USB 2.0
1 * RJ45 LAN (10/100/1000)
1 * 3.5mm MIC-in Jack
1 * 3.5mm Line-out (S/SDIF) Jack
WiFi MINI PCI-E WIFI CARD + ANTENNA
Adapter: Slim 8XDVD
IPC VGA Card: NVIDIA GT610 PCI-E 1X 1GB 64bit/SDDR3 DVI-I+HDMI+CRT Heatsink 27.2W
PCIe 1X Riser Card PCIe 1X Riser Card Card
Adapter: 90W (19V) A/C Adapte
Input Voltage: A/C 100~240V
OS: N/A

Application
Home Media Center
Video Wall
Video Media
HTPC
Server





2012年8月18日 星期六

Thunder (T-3420) - Fanless Solution is perfect for Thin Client Solution


1) Chassis: Thunder (T3420) Mini-ITX Chassis; 73mm (H) * 320mm(W)*202mm (D)2) Mainboard: Intel D250CC3) Memory Module: 2.0G DDR3 SODIMM4) 2.5" 32~120GB Hard Drive or SSD5) Power Supply: 60W 12 5A AC-DC Power Adapter & Power Cord6) Front Port: USB * 2, Audio *1, Mic *1









2012年4月12日 星期四

T1620 Super Mini ITX - Designed for Intel DN2800MT Mainboard

T1620 Chassis is Fanless, low-profile case designed for the Intel DN2800MT ("Marshalltown") mainboard. Sturdy and compact, the T-1620 offers a variety of mounting and display options. Excellent for nettop, industrial control, and light digital signage applications.

FEATURES
T-1620 is an entry-level fanless enclosure designed for the Intel DN2800MT ("Marshalltown") Thin Mini-ITX mainboard. Lightweight, and ultra-slim, the T-1620 takes advantage of the Marshalltown's low-profile design. Because the DN2800MT board has integrated DC power, the case dimensions conform almost exactly to the size of the board, making a super small footprint system with dual core Atom processing performance. With the included accessories, the case can either stand upright or flat, or can be VESA-mounted to the back of an LCD screen. The T-1620's versatility makes it at home as either a desktop replacement or a discreet installation.

T-1620 is completely fanless. When paired with the Marshalltown fanless mainboard, sufficient airflow from the surrounding environment is required.
